China's first C-type 1250T large ship special equipment landing project in Dalian Shipyard

The series of presses is mainly used for shipbuilding and other industries such as thick plate bending, folding, leveling, etc., as well as the ship's outer plate line type, pressing groove isolation, marine tanks and other hot and cold molding process, but also petrochemical, boiler and other industrial areas of thick plate molding processing of the key equipment.

Category

Large Ship Bottleneck Project

E-mail

18012235588@163.com

Key words

China's first C-type 1250T large ship special equipment landing project in Dalian Shipyard

Consult Also Like

PRODUCT DETAILS

Characteristics

My factory production singlecolumn hydraulic press has YTD30 and the YTD41 twokinds, the fuseage welds C Shan Bishi for Jin'gang thestructure, after the limited design guaranteed the highrigidity, the redundant reliability, afer the weidingthrough the lempering aging treatment ol metalguarantees the fuselage not to distort. The rydraulicsystem is located in the fuselage, the contour isartistic, ease of operation, The oil pump oil in is loadedwith the indepandent filtrating equipment, guaranteestha oil pump and the valve service life, uses accordingto turns the common control, may realize decides theregulation and the constant pressure two kinds takesshape the craft, the slide four guide pillars guidances,increases the product precision,regarding thecustomer special request,we maydesgn theproduction specially, maximum limit satisfied customerproduction technological requirement.
Applications

The metal product stretches, takesshape and the pressure installs and so on the craft,aiso may process the nonmetallic material, the powdermetallurgyprduct suppression,the axiscasscomponents adjustment, the set of kind of componentsprossure installs as well as craft and so on metalproduct reshaping, cutting edge.
Options

◆Auxiliary work table◆Precise schoolstraight systemePhotoelectricity protective deviceTouches the type industry display moniloreTheproportion velocitymodulationsystem rydraulicsystem heats upeCooling systemeHits the materialinstallmentePLC programmable foreword con'rolThe bracket hangs

Ltem		Unit	YTD41-16	YTD41-25	YTD41-40B	YTD41-63	YTD41-100E	YTD41-160	YTD41-200
Nominal force		kN	160	250	400	630	1000	1600	2000
Feturn force		kN	25	35	60	60	100	170	240
Max.prassure of liqud		Mpa	12.5	12.5	20	20	25	25	25
Max slide strnkA		mm	400	500	500	500	500	500	600
Side to work tible maximun rng		mm	600	600	600	630	760	900	900
Throat depth		mm	250	320	320	320	350	360	360
Slido speed	Ouick under	mm/s	80	80	80	80	90	90	100
	Work	mm/s	15-20	12-20	12-20	6-13	8-15	8-14	6-12
	Retun trip	mm/s	120	120	120	120	130	130	100
Table area	L-R	mm	500	510	600	700	700	800	900
Table area	F-B	mm	450	580	500	600	600	630	700
Slide area	L-R	mm	320	340	340	380	500	600	550
Slide area	F-B	mm	320	340	340	380	500	450	500
Total power		kw	3	3	7.5	7.5	11	15	15

Ltem		Unit	YTD41-315	YTD41-500A	YTD41-500B	YTD41-500C	YTD41-800	YTD41-1000	YTD41-1250
Nominal force		kN	3150	5000	5000	5000	8000	10000	12500
Feturn force		kN	600	950	950	950	480	1300	1700
Max.prassure of liqud		Mpa	25	25	25	25	25	25	25
Max slide strnkA		mm	800	800	900	900	600	1250	1500
Side to work tible maximun rng		mm	1500	1200	1500	1500	1200	3200	2700
Throat depth		mm	1300	800	1500	1800	550	1800	2500
Slido speed	Ouick under	mm/s	90	100	100	100	100	100	100
	Work	mm/s	6-12	6-13	6-13	6-13	4-8	8-15	4-10
	Retun trip	mm/s	60	70	7	70	120	120	60
Table area	L-R	mm	2000	1800	2500	2500	2800	4000	4000
Table area	F-B	mm	1700	1800	1400	1400	1000	3000	4000
Slide area	L-R	mm	1200	1000	1000	1200	950	3000	2000
Slide area	F-B	mm	1000	800	1000	1000	950	1500	2000
Total power		kw	30	37	37	37	37	75	74

Product Accessories:

NONE
